Digital Finishing Cutting System

Ask Lasest Price
Brand Name :	CUTCNC
Certification :	CE, ISO9001:2008 and others upon request.
Delivery Time :	15-25 working days
Payment Terms :	T/T
Supply Ability :	500set/year

Add to Cart

Product Details
Company Profile

Digital Finishing Cutting System

Partnered with UV flatbed inkjet printer and vision register system or laser position, CUTCNC flatbed cutter offer perfect print-cut register align cutting serivce. Widely applied in advertising, CUTCNC flatbed cutter offer precise contour cutting for flatbed printed substrates materials like KT board,foamex,vinyl decal,rigid PVC, acrylic board,honeycomb board,coroplast,corrugated cardboard,etc.

Whether for prototyping, sample making, short run production or digital die cutting, CUTCNC is your effcicent solution supplier.

Brief introduction:

◇Four tools: oscillating knife, drag knife, pen and creasing wheel.

◇Perfect cutting performance.

◇Do not need to change tools for half cut boutique gift box

◇Equipped safety guard system to avoid injury.

◇Brunt model sold well in EU,USA and overseas market

Functions:
◇It can cut many different materials (such as corrugated paper, leather,card paper, offset paper, grey board, compound materials, gasket and textile)
◇It can fold corrugated paper, card paper and offset board into perfect folding line.
◇It can half cut ,whole cut, crease and dotted line.
◇Using laser lamp improve location precision
◇Using for sample maker or small batch of production.

Specifications:

Effective cutting area	2500*1600mm	1700*1300mm	1300*1000mm
Configuration	oscillating knife, drag knife, pen, creasing wheel.
Option	video registration, v cut knife, router system, foam cutting knife, convey belt,
Max speed	1400mm/s
Maximum cutting thickness	60mm
Precision	≤0.1mm
Voltage	220v±10% 50Hz
Smallest cutting diameter	6mm
Occupy dimension(LWH)	340024601180mm	260021601180mm	220018601180mm
Note: other sizes can be customized.
